FEATURES
• Server-side conversion supports STEP 3D file format (.stp, step)
• Server-side conversion supports IGES 3D file formats (.igs, .iges)
• Server-side conversion supports FBX 3D file format (.fbx、.dae、.obj)
• Server-side conversion supports Catia V4 3D file format (. model,. dlv,.dlv3,.exp,.session)
• Server-side conversion supports Catia V5 3D file format (. CATPart,. CATProduct)
• Server-side conversion supports Catia V6/3DEXPERIENCE 3D file format (. 3dxml)
• Server-side conversion supports PARASOLID 3D file format (. x_t,.x_b,.xmt_txt,.xmt_bin)
• Server-side conversion supports SolidWorks 3D file format (. sldprt,.sldasm)
• Server-side conversion supports Solid Edge 3D file format (. par,.psm,.asm,.sldasm)
• Server-side conversion supports ProE/Creo Parametric 3D file format (. par,.xpr,.asm,.xas)
• Server-side conversion supports DWG/DXF 3D file format (.dwg,.dxf)
• Server-side conversion supports IFC 3D file format (.ifc)
• Server-side conversion supports Inventor 3D file format (.ipt,.iam)
• Server-side conversion supports Rhino 3D file format (.3dm)
• Provides cli conversion function
• Provides server conversion source code
• The client supports WebGL, IOS, Android, Mac, Windows, Editor platform loading
• Supports built-in render pipelines, URP render pipelines, HDRP render pipelines
• Supports Chinese name import
• Support multidimensional sub-material import
The server-side converter only supports Window systems or window server systems.
CAD Server differs from CAD Import
1. The transformation of the CAD Server model is on the server side, and the client loads the converted data on the server side.
2. Because the CAD model conversion is converted on the server, more client platforms are supported to load the CAD model.
THIRD-PARTY ASSETS
- Asset uses Newtonsoft Json.NET under MIT License; see Third-Party Newtonsoft.Json_License.txt file in package for details.
- Asset uses UnityGLTF under MIT License; see Third-Party UnityGLTF_License.txt file in package for details.
- Asset uses SharpZipLib under MIT License; see Third-Party SharpZipLib_License.txt file in package for details.
Online WebGL Client Examples Link（如遇无法打开网页，请科学上网访问）:
https://n3gis.github.io/CADServerPro.html
Description sourced from the Unity Asset Store listing.
